HLG-60H-C-SPEC

81 AUD – 84 AUD

HLG-60H-C

Brand: Mean Well
Warranty: 24 months
GENUINE PRODUCTS GUARANTEED

SKU: N/A Categories: ,

HLG-60H-C

Catalogue HLG-60H-C

MODEL HLG-60H-C350 HLG-60H-C700








OUTPUT

 RATED CURRENT 350mA 700mA
RATED POWER 70W 70W
CONSTANT CURRENT REGION Note.2 100 ~ 200V 50 ~ 100V


CURRENT ADJ. RANGE

 Adjustable for A-Type only (via built-in potentiometer)
210 ~ 350mA 420 ~ 700mA
CURRENT RIPPLE 5.0% max. @rated current
CURRENT TOLERANCE ±5%
SET UP TIME                                   Note.4 750ms/115VAC, 500ms/230VAC
















INPUT

 VOLTAGE RANGE                                   Note.3 90 ~ 305VAC     127 ~ 431VDC

(Please refer to “STATIC CHARACTERISTIC” section)
FREQUENCY RANGE 47 ~ 63Hz
POWER FACTOR (Typ.) PF≧0.98/115VAC, PF≧0.96/230VAC, PF≧0.94/277VAC @full load

(Please refer to “POWER FACTOR (PF) CHARACTERISTIC” section)
TOTAL HARMONIC DISTORTION THD< 20% (@ load≧60% /115VAC, 230VAC; @ load≧75%/277VAC)

(Please refer to “TOTAL HARMONIC DISTORTION (THD)” section)
EFFICIENCY (Typ.) 91% 90.5%
AC CURRENT (Typ.) 0.69A / 115VAC    0.35A / 230VAC    0.29A / 277VAC
INRUSH CURRENT(Typ.) COLD START 60A(twidth=275μs measured at 50% Ipeak) at 230VAC; Per NEMA 410
MAX. No. of PSUs on 16A CIRCUIT BREAKER 8 units (circuit breaker of type B) / 13 units (circuit breaker of type C) at 230VAC
LEAKAGE CURRENT <0.75mA / 277VAC




PROTECTION

 SHORT CIRCUIT Hiccup mode, recovers automatically after fault condition is removed
OVER VOLTAGE 230 ~ 250V 120 ~ 140V
Shut down o/p voltage with auto-recovery or re-power on to recovery
OVER TEMPERATURE Shut down o/p voltage, re-power on to recover








ENVIRONMENT

 WORKING TEMP. Tcase=-40 ~ +80℃(Please refer to “OUTPUT LOAD vs TEMPERATURE” section)
MAX. CASE TEMP. Tcase=+80℃
WORKING HUMIDITY 10 ~ 95% RH non-condensing
STORAGE TEMP., HUMIDITY -40 ~ +80℃, 10 ~ 95% RH
TEMP. COEFFICIENT ±0.03%/℃ (0 ~ 50℃)
VIBRATION 10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes






SAFETY & EMC

 SAFETY STANDARDS  Note.6 UL8750, CSA C22.2 No. 250.0-08, EN/AS/NZS 61347-1,EN/AS/NZS 61347-2-13 independent, GB19510.1,GB19510.14,

EAC TP TC 004,IP65 or IP67, J61347-1,J61347-2-13 approved
WITHSTAND VOLTAGE I/P-O/P:3.75KVAC  I/P-FG:2KVAC  O/P-FG:1.5KVAC
ISOLATION RESISTANCE I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH
EMC EMISSION                                   Note.6 Compliance to EN55015, EN61000-3-2 Class C (@ load≧60%) ; EN61000-3-3,GB17743 and GB17625.1, EAC TP TC 020
EMC IMMUNITY Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, heavy industry level (surge immunity Line-Earth 4KV, Line-Line 2KV), EAC TP TC 020


OTHERS

 MTBF 878.1K hrs min. Telcordia SR-332 (Bellcore) ;  338K hrs min.                     MIL-HDBK-217F (25℃)
DIMENSION 171*61.5*36.8 mm (L*W*H)
PACKING 0.73Kg; 20pcs/15.6Kg/0.9CUFT



Contact information: Van Hao Pty Ltd- Mean Well Australia

–  Address: 1A Welfare Parade Ashburton VIC, 3147Australia
– Phone: +61398853030
– Email: meanwell168@gmail.com / nguonvn.meanwell@gmail.com
– Website: https://meanwellaustralia.au/

Voltage Required

3.3V, 5V, 12V, 15V, 24V, 27V, 36V, 48V
